Hays Twister 3/4 Race Torque Converters Good names never go away, and neither should good terms!

Features and Benefits:

• 3/4 Race series converters are built, tested, and proven to support up to 650 HP.
• State of the art Spray Welding process is used in select areas. Spray Welding provides clean, strong and consistent fusion while also increasing strength through hardening from higher process temperature
• Each converter is hand-built and inspected in every step of assembly to ensure top of the line quality
• All Hays converters are internally welded compared to brazing. Testing has shown welding provides longer converter life while also enhancing consistency
• Heavy duty Torrington bearings are used for greater strength and durability
• Stators are chosen with high flow vents and channels to promote cooling in heat producing higher horsepower applications
• Increased horsepower and acceleration due to a weight saving, one application design. Almost all Hays converters are built for one application to reduce weight compared to a multi-bolt pattern converter.
• 3/4 Race series converters are offered in several different stall speeds for GM, Ford, and Chrysler transmissions
• Industry leading Tech Support Team is available to provide assistance with stall speed selection

Details:

• Anti-Balloon Plate: No
• Balanced: Yes
• Bolt Circle: 10.75 Inch
• Crank Pilot Diameter: 1.703 Inch
• Diameter: 9.6 Inch
• Emission Code: 5
• Input Spline: 27
• Lock Up/Overdrive: Yes
• Series: 3/4 Race
• Stall: 3200-3600
• Transmission: 700R4|200R4|2004R|700R4
• Use with Power Adder: No
• Use with Trans-Brake: No

Application Summary:

• 1450 1991 Isuzu Pickup S LS
• 1982-1989 Buick Electra Estate Wagon Limited Park Avenue
• 1982-1983 Buick Estate Wagon Base
• 1982-1990 Buick LeSabre Limited Custom Limited Edition F/E Estate Wagon Collector's Edition
• 1982-1987 Buick Regal Base Limited Estate Wagon Limited Turbo Sport T-Type Grand National GNX
• 1991-1993 Buick Roadmaster Estate Wagon Limited Base
• 1991-1993 Buick Commercial Chassis Base
• 1985-1993 Cadillac Commercial Chassis Base Brougham
• 1982-1984 Cadillac DeVille Cabriolet Base d'Elegance
• 1982-1993 Cadillac Fleetwood Brougham Brougham d'Elegance Formal Base
• 1987-1992 Cadillac Brougham d'Elegance Base
• 1985-1992 Chevrolet Astro Base CS CL LT
• 1987-1993 Chevrolet Blazer Silverado Custom Deluxe Scottsdale Cheyenne
• 1982-1986 Chevrolet K5 Blazer Custom Silverado Scottsdale
• 1982-1986 Chevrolet C10 Silverado Scottsdale Custom
• 1982-1986 Chevrolet C10 Suburban Custom Silverado Scottsdale
• 1988-1992 Chevrolet C1500 Silverado Cheyenne Scottsdale WT
• 1992 Chevrolet C1500 Suburban Silverado Base
• 1982-1986 Chevrolet C20 Scottsdale Silverado Custom
• 1982-1986 Chevrolet C20 Suburban Custom Silverado Scottsdale
• 1988-1992 Chevrolet C2500 Silverado Cheyenne Scottsdale
• 1992 Chevrolet C2500 Suburban Silverado Base
• 1982-1986 Chevrolet C30 Scottsdale Custom Silverado
• 1988-1990 Chevrolet C3500 Silverado Cheyenne Scottsdale
• 1983-1993 Chevrolet Camaro Z28 Sport Berlinetta Iroc-Z LT Base RS Z28 Heritage Edition RS Heritage Edition Indianapolis 500 Pace Car
• 1982-1993 Chevrolet Caprice Classic Classic Estate Base Classic Brougham Classic LS Brougham Classic LTZ Classic LS
• 1982-1993 Chevrolet Corvette Base Collector's Edition Indianapolis 500 Pace Car 35th Anniversary Edition 40th Anniversary Edition
• 1982-1987 Chevrolet El Camino SS Base Conquista
• 1983-1992 Chevrolet G10 Beauville Sportvan Chevy Van Bonaventure Base
• 1983-1992 Chevrolet G20 Sportvan Chevy Van Beauville Bonaventure
• 1983-1992 Chevrolet G30 Chevy Van Hi-Cube Sportvan Beauville Bonaventure

Associated Comments:

• Warning: The 3/4 Race series converters are NOT designed to be used with Nitrous Oxide or Trans-Brakes
• Note: Hays recommends an external transmission cooler for all Twister 3/4 Race Converters
• (A minimum size of 18,000 GVW or 15,000 BTU Rating.)
• Note: Stall ranges will vary depending on engine set-up, weight of vehicle, and gear ratio (Please see converter selector in tech resources for more info)
