A modern twist on a familiar name in ignition performance is back! The Mallory HyFire needs no introduction. Packed inside the retro case are modern electronics ready to deliver a powerful ignition punch.

The HyFire is a capacitive discharge ignition that supplies multiple sparks at low RPM's for a clean idle and quick throttle response. Since the HyFire provides powerful spark through redline, a built in adjustable rev limiter will help tame your beast in case of a missed shift or driveline failure. The rev limiter is adjustable in 100 RPM increments with easily adjustable rotary dials.

Features and Benefits:

• Modern capacitive discharge ignition technology
• Retro design for classic good looks
• Connects easily to points, amplifiers and magnetic pickup distributors
• Adjustable rev limiter for overrev protection
• Multiple sparks at low RPM for improved starting, clean idle and snappy throttle response

Details:

• Color: Black
• Current Draw: .7 Amp per 1,000 RPM
• Emission Code: 3
• Primary Voltage: 435В Volts
• RPM Range: 15,000В RPM with 14.4 Volts
• Secondary Voltage: 43,000 Volts
• Spark Energy: 95В mJ per spark
• Spark Series Duration: 20В° Crankshaft Rotation
• Voltage Required: 10-18 Volts, Negative Ground
• Weight and Size: 2.82lbs., 6.875 inch L x 4.0 inch W x 3.375 inch H
