SKU
300-4-BBVL
List price
$449.95
Price
$359.95

Carburetor Intake Manifold 396ci-502ci with Oval Port Heads

Features and Benefits:

  • Height: Front 4.75 inch, Rear 6.25 inch Single Plane/Open Plenum Design Deep Plenum Design with Isolated Runners Port Size: 1.85 inch height 1.60 inch width 4150 Square Bore Carburetor Mounting Flange Power band: 4500-8500 RPM

Associated Comments:

  • Will fit tall blocks with use of Weiand spacer plate kit, P/N 8204. Accepts 850-1000 CFM Holley HP 4bbl carburetor.

Details:

  • Basic Operating RPM Range: 4500-8500 RPM
  • Cnc Ported: No
  • Carburetor Flange: 4150 Square Bore
  • Carburetor Quantity: 1.0
  • Carburetor Studs Included: No
  • Color: Natural
  • Construction: Cast
  • Cylinder Head Port Shape: Oval
  • Deck Height: 9.8 Inch
  • Egr Port: No
  • Engine: Chevy Big Block - Oval Port
  • Flange Style: 4150 Square Bore
  • Front Maximum Height: 4.77 Inch
  • Fuel Injectors Included: No
  • Fuel Rail(s) Included: No
  • Fuel System Type: Carb
  • Gasket Or Seal Included: No
  • Grade Type: Performance
  • Intake Port Gasket(s) Included: No
  • Manifold Type: High Rise
  • Material: Aluminum
  • Nitrous Bung(s) Included: No
  • Plenum Finish: Natural
  • Rear Maximum Height: 6.16 Inch
  • Removable Runners: No
  • Removable Top/Lid: No
  • Single Or Dual Plane Type: Single Plane
  • Throttle Body Bore Diameter: 3.6
  • Throttle Body Gasket Included: No
  • Throttle Body Included: No
  • Vacuum Ports: No
  • Warranty: Manufacturer's Limited 90 Day Warranty
CALIFORNIA WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Vehicle Fitment
1963 Chevrolet Impala
1963 Chevrolet Bel Air
1963 Chevrolet Biscayne
1965-1976 Chevrolet Impala
1965-1973 Chevrolet Bel Air
1965-1972 Chevrolet Biscayne
1965-1974 Chevrolet Corvette
1965-1967 Chevrolet Impala SS
1966-1972 Chevrolet Caprice
1967-1969 Chevrolet Camaro SS
1967 Chevrolet Camaro RS
1967 Chevrolet Camaro
1968-1969 Chevrolet C10 Pickup
1968-1969 Chevrolet C30 Pickup
1968-1969 GMC C25/C2500 Pickup
1968-1969 GMC K35/K3500 Pickup
1968-1969 Chevrolet K30 Pickup
1968-1969 Chevrolet K20 Pickup
1968-1969 GMC K15/K1500 Pickup
1968-1969 Chevrolet C20 Pickup
1968-1969 GMC K25/K2500 Pickup
1968-1969 GMC C35/C3500 Pickup
1968-1969 GMC C15/C1500 Pickup
1968-1969 Chevrolet K10 Pickup
1969-1972 Chevrolet Brookwood
1969-1972 Chevrolet Kingswood Estate
1969-1970 Chevrolet Estate
1969-1970 Chevrolet Nova
1969-1972 Chevrolet Townsman
1969-1972 Chevrolet Kingswood
1970-1971 Chevrolet P20 Van
1970-1974 Chevrolet Monte Carlo
1970-1971 Chevrolet P30 Van
1970-1971 GMC P25/P2500 Van
1970-1971 GMC P35/P3500 Van
1971-1972 Chevrolet Chevelle SS
1972 Chevrolet Camaro SS
1972 Chevrolet Camaro Z28
1972 Chevrolet Camaro
1973-1974 Chevrolet P30 Van
1973-1974 Chevrolet G20 Van Sportvan
1973 Chevrolet P20 Van
1973-1974 GMC K35/K3500 Pickup
1973 Chevrolet Monte Carlo S
1973-1974 GMC C25/C2500 Pickup
1973-1976 Chevrolet Caprice Classic
1973-1974 Chevrolet Caprice Estate
1973-1974 Chevrolet K30 Pickup
1973 Chevrolet Chevelle Deluxe
1973-1974 Chevrolet C20 Pickup
1973-1974 GMC K25/K2500 Pickup
1973-1974 GMC C35/C3500 Pickup
1973-1974 Chevrolet G30 Van
1973-1974 Chevrolet G20 Van
1973-1974 GMC P35/P3500 Van
1973-1974 Chevrolet C30 Pickup
1973-1974 Chevrolet K20 Pickup
1973-1974 Chevrolet Monte Carlo Landau
1974 GMC P35/P3500 Van Motorhome
1975 Chevrolet Caprice Estate Wagon
1975-1976 Chevrolet G30 Hi-Cube
1975-1978 GMC C25 High Sierra
1975-1978 GMC C35 High Sierra
1975-1978 GMC C35 Sierra Classic
1975-1976 GMC G25 Rally
1975-1976 GMC G25 Rally STX
1975-1986 Chevrolet C20 Scottsdale
1975-1986 Chevrolet C30 Scottsdale
1975-1978 GMC C25 Sierra Classic
1975-1978 GMC C35 Sierra Grande
1975-1978 GMC C25 Sierra Grande
1975-1986 Chevrolet C20 Silverado
1975-1986 Chevrolet C30 Silverado
1975-1976 Chevrolet Impala Sport
1975-1980 Chevrolet C20 Custom Deluxe
1975-1980 Chevrolet C30 Custom Deluxe
1975-1976 Chevrolet G30 Beauville
1975-1976 Chevrolet G30 Chevy Van
1975-1981 Chevrolet C30 Cheyenne
1975-1978 GMC C25
1975-1978 GMC C35
1975-1981 Chevrolet C20 Cheyenne
1975-1976 Chevrolet Impala Custom
1975-1976 Chevrolet Caprice Classic Sport
1976-1978 GMC K25 Sierra Grande
1976-1978 GMC K25 Sierra Classic
1976 Chevrolet G20 Beauville
1976-1978 Chevrolet K20 Silverado
1976-1978 Chevrolet K20 Scottsdale
1976 Chevrolet G20 Chevy Van
1976 Chevrolet Impala S
1976-1978 Chevrolet K20 Cheyenne
1976-1978 GMC K25 High Sierra
1976 GMC G35 Magnavan
1976-1978 Chevrolet K20 Custom Deluxe
1976 Chevrolet Impala Custom Landau
1976-1978 GMC K25
1976 Chevrolet Caprice Classic Landau
1976 Chevrolet Caprice Classic Estate
1977 Chevrolet K30 Silverado
1977 Chevrolet K30 Scottsdale
1977 Chevrolet K30 Custom Deluxe
1977 Chevrolet K30 Cheyenne
1979-1986 GMC K3500 Sierra Classic
1979-1982 GMC C3500 Sierra Grande
1979-1986 GMC C2500 Sierra Classic
1979-1982 GMC C2500 Sierra Grande
1979-1986 GMC C3500 Sierra Classic
1979-1982 GMC K3500 Sierra Grande
1979-1986 GMC C2500
1979 GMC P1500
1979-1986 GMC K3500
1979-1986 GMC C3500
1979-1986 GMC C3500 High Sierra
1979-1986 GMC C2500 High Sierra
1979-1986 GMC K3500 High Sierra
1979 GMC P1500 Value Van
1980 Chevrolet K20 Scottsdale
1980-1986 Chevrolet K30 Scottsdale
1980 Chevrolet K30 Custom Deluxe
1980 Chevrolet K20 Cheyenne
1980-1981 Chevrolet K30 Cheyenne
1980 Chevrolet K20 Custom Deluxe
1980 Chevrolet K20 Silverado
1980-1986 Chevrolet K30 Silverado
1981-1982 Chevrolet P30 Step-Van
1981-1982 Chevrolet P30
1981-1986 Chevrolet C30 Custom
1981-1986 Chevrolet K30 Custom
1981 Chevrolet C30 Deluxe
1981 Chevrolet C20 Deluxe
1981 Chevrolet K30 Deluxe
1981-1986 Chevrolet C20 Custom
1987 GMC R3500
1987 GMC R3500 Sierra Classic
1987-1988 Chevrolet R30 Custom Deluxe
1987-1988 Chevrolet V30 Custom Deluxe
1987-1988 Chevrolet R30 Silverado
1987-1988 Chevrolet V30 Silverado
1987 GMC R3500 High Sierra
1987-1988 Chevrolet R30 Scottsdale
1987-1988 Chevrolet V30 Scottsdale
1988 Chevrolet V30 Cheyenne
1988 Chevrolet R30 Cheyenne
1988-1989 GMC C3500 Sierra SLX
1988-1989 GMC C3500 Sierra SLE
1988-1989 GMC C3500 Sierra
1989 Chevrolet V3500 Silverado
1989 Chevrolet R3500 Silverado
1989 Chevrolet V3500 Cheyenne
1989 Chevrolet R3500 Cheyenne
1989 Chevrolet V3500 Scottsdale
1989 Chevrolet R3500 Scottsdale
Installation Instructions
800bb57ab6179035d1e133e89c154098_0.pdf (317.17 KB)
Brand
Holley
Category
Performance
Engine and Components
Engine
Engine Intake Manifold
Color
Natural
Material
Aluminum
Specs
Country of Origin: USA
Sold As: Each
UPC: 90127053232
Availability: Available
Universal: No
Vehicle Type
Car
Core Charge
$0.00
